Single-Phase Aluminum Series

Frame number: 56-132 frame
Output power: 0.09~ 7.5kW
Rated voltage: 110, 220V or other voltage
Rated frequency: 50HZ or 60HZ
Working system: Continuous working system S1
Protection level: IP54/IP55
Cooling mode: IC411
Insulation class: F grade insulation
Installation:
IMB3 (horizontal foot mount);
IMB5 (horizontally mounted with large flange);
IMB34 (horizontal foot mount with small flange);
IMB35 (horizontal foot mount with large flange); For mounting dimensions, refer to the attached table.
